Organic Impregnation Agents Technical Data
HY-90C
Low viscosity, high permeability, low shrinkage, curing tough, strong sealing.
Cured body temperature (-50 ℃ / + 220 ℃), oil resistance, solvent resistance, chemical resistance, water resistance.
Good washing performance, without leaving Baptist exudate after M4 blind holes cleaning.
Meet ROHS requirements
Application Scope: infiltration sealing of powder metallurgy parts and metal casting parts.
Ingredient |
Acrylate mixture |
Exterior | Colorless transparent liquid |
Flavor | Micro-ester flavor | Proportion（20℃） | 1.04g/ml |
Viscosity（20℃） | 9-11mPa.5 | Flash point | 100℃ |
Washing performance | Good | Curing time (90 ℃ hot water) | 210-270s |
Instructions | Main agent + curing agent | Cured parts heat resistance temperature | -50/+220℃ |
Life Span (under specified conditions) | 3 years | Cured parts weatherability | Very good |
Storage method | Avoid high temperature and direct light | Environmental characteristics | Non-toxic, ROHS |
HY-901
Low viscosity, high permeability, low shrinkage, strong bond with the metal, excellent sealing performance
Cured body temperature （-40℃/+200℃）, oil resistance, solvent resistance, chemical resistance, water resistance
Good washing performance, without leaving Baptist exudate after M4 blind holes cleaning
Meet ROHS requirements
Application Scope: infiltration sealing of all kinds of precision machining casting parts
Ingredient | Acrylate mixture | Exterior | Colorless transparent liquid |
Flavor | Micro-ester flavor | Proportion（20℃） | 1.06g/ml |
Viscosity（20℃） | 7-9mPa.5 | Flash point | 100℃ |
Washing performance | Good | Curing time (90 ℃ hot water) | 210-270s |
Instructions | Main agent + curing agent | Cured parts heat resistance temperature | -40/+220℃ |
Life Span (under specified conditions) | 3 years | Cured parts weatherability | Very good |
Storage method | Avoid high temperature and direct light | Environmental characteristics | Non-toxic, ROHS |
HY-902
Low viscosity, high permeability, low shrinkage, curing tough, strong sealing
Cured body temperature (-50 ℃ / + 220 ℃), oil resistance, solvent resistance, chemical resistance, water resistance
Good washing performance, without leaving Baptist exudate after M4 blind holes cleaning
Meet ROHS requirements
Application Scope: infiltration sealing of powder metallurgy parts and metal casting parts.
Ingredient | Acrylate mixture | Exterior | Colorless transparent liquid |
Flavor | Micro-ester flavor | Proportion（20℃） | 1.06g/ml |
Viscosity（20℃） | 7-9mPa.5 | Flash point | 100℃ |
Washing performance | Good | Curing time (90 ℃ hot water) | 210-270s |
Instructions | Main agent + curing agent | Cured parts heat resistance temperature | -40/+220℃ |
Life Span (under specified conditions) | 3 years | Cured parts weatherability | Very good |
Storage method | Avoid high temperature and direct light | Environmental characteristics | Non-toxic, ROHS |
HY-90R
Recovery type, recycled by simply water-liquid separation
Low viscosity, high permeability, low shrinkage, excellent sealing performance
Temperature (-50 ℃ / + 200 ℃), oil resistance, solvent resistance, chemical resistance, water resistance
No waste water discharge, water recycling, excellent environmental performance
Application Scope: general metal casting, powder metallurgy
Ingredient | Acrylate mixture | Exterior | Colorless transparent liquid |
Flavor | Micro-ester flavor | Proportion（20℃） | 0.91-0.92g/ml |
Viscosity（20℃） | 3-4mPa.5 | Flash point | 100℃ |
Washing performance | Good | Curing time (90 ℃ hot water) | 180-240s |
Instructions | Main agent + curing agent | Cured parts heat resistance temperature | -50/+200℃ |
Life Span (under specified conditions) | 3 years | Cured parts weatherability | Excellent |
Storage method | Avoid high temperature and direct light | Environmental characteristics | Non-toxic, ROHS |
